1.Performance |
|
Standards Compliance |
DisplayPort 1.4/HBR3, HDCP 1.4/2.2 |
|
Maximum Pixel Clock Frequency |
810 MHZ |
|
Maximum Video Bit Rate |
Supports up to 8.1 Gbps per lane, 32.4 Gbps Total |
|
Maximum Color Depth |
48bits |
|
Maximum Supported Resolutions |
8K@ 60Hz |
|
Maximum Cable Length |
100 meters |
|
2.Connections |
|
DisplayPort Input / Output |
20-pin DisplayPort |
|
Power |
No external power supply is required. |
|
3. AUX Channel support |
|
AUX Channel Communications |
Supports bidirectional communications for EDlDHDCP, Link Training, etc. |
|
HDCP Support |
HDCP 1.4 and HDCP 2.2 |
|
4.Mechanical-Cable |
|
Maximum Tensile Load |
300N |
|
Minimum Bend Radius |
48mm |
|
Cable Outside Diameter (W x H) |
4.8mm |
|
5.Environmental |
|
Operating Temperature |
0℃: to+ 50℃ |
|
Storage Temperature |
-20℃ to + 85℃ |
|
Operating / Storage Humidity |
5% to 85% (non-condensing) |
|
6.Power Requirements |
|
Power Source |
Powered from DisplayPort source devce |
|
Power Consumption |
< 0.5 watt each end |
